SmartGen BAC2403VE (24V3A) Battery Charger, Vertical, rail-type mounting

BAC2403VE switching battery charger adopts the latest switch power components, which is designed for charging lead-acid starting battery according to its property. The charger is suitable for lead-acid battery float charge.

PERFORMANCE AND CHARACTERISTICS:
1. Designed in switching power structure, wide range of AC voltage input, small volume, light weight and high efficiency;
2. Two-stage charging method (constant current firstly and then constant voltage), fully considering charging property of the lead-acid battery, can avoid overcharging and extent extend the battery life to the fullest;
3. With short circuit and reverse connection protection;
4. Charging voltage can be adjusted via potentiometer on the spot (breaking the connection between the batteries when adjusting);
5. LED display: charging indication and full charged indication;
6. Vertical type (35mm guide-rail way and screw fixed way) for installation and furthest decreased installation dimension
